Ares V Expanded
30" x 24" 300 ppi Digital Illustration (2007)
© Alliant Techsystems Inc.



NASA's Ares V Launch Vehicle and Altair Lunar Lander includes two of ATK's 5-segement Reuseable Solid Rocket Motors and five RS-68 engines. The Ares V will be one of NASA's new generation of Launch Vehicles that will take America to the Moon and beyond in the 21st Century.

More images at ATK's Safe Simple Soon Website. http://safesimplesoon.com.

Artist's Note: This illustration was created with Autodessyes FormZ 6.0/Renderzone and Adobe Photoshop CS2. Hardware was an Apple Power Macintosh G5 Dual 2.5 Ghz and a Wacom Intuos Graphics Tablet.

2310 x 3300 image


Many of the ATK paintings are available as high quality lithographs through ATK Launch Systems, MS PUBS, PO Box 707, Brigham City, Utah 84302. While not normally available to the general public, the prints are available to military units, aerospace organizations and industry representatives. Reproduced with permission of Alliant Techsystems, Inc. Unauthorized use of this image is strictly forbidden.
